An enamel biogas tank for digestion and sludge — unaffected by the hydrogen sulphide that destroys concrete digesters.
Indicative — the quotation confirms the final figure US$3,600 Lead time within 15 working days · ex Dezhou, Shandong
SKU LVJ-EN-BIO
What buyers said once the tank was on site — every review left on our Alibaba store, in their own words.
The enamel biogas tank from LVJIA is built on the Enameled panel system at our own plant in Dezhou, Shandong. In a digester the gas above the sludge is far more destructive than the sludge itself, and that is where tanks fail.
An enamel biogas tank is a bolted tank whose steel panels are fired with a glass glaze at high temperature, so the surface meeting the water is chemically glass rather than metal. It does not rust, it takes no coating and it adds no taste, and the glaze is fused into the steel rather than painted onto it. Panels come in 3 × 1 m; 2 × 1 m; 1.5 × 1 m; 1 × 1 m; 1 × 0.5 m; 0.5 × 0.5 m, and the tank is rated for water between 4 and 100 °C.
Anaerobic digestion produces hydrogen sulphide, which dissolves in the moisture condensing on the roof and walls above the liquid and oxidises into sulphuric acid. Concrete is eaten away from the gas space downwards and steel corrodes rapidly in the same zone, which is why so many digesters fail at the top rather than the bottom. Glass fused to steel is inert to both the sulphide and the acid, so the gas space lasts exactly as long as the wetted section below it.
The panel is pressed from 2 to 4.5 mm steel depending on where it sits in the wall, then enamelled on both faces so the outside is protected as well as the inside. Assembled, the wall section measures 12 mm. Panels bolt together on a sealed joint, and because the glaze is inert the same tank handles potable water, fire reserve and mildly aggressive process water without a change of specification. LVJIA runs the enamel line at Dezhou under ISO 9001.
| Model number | Enamel Water Tank |
|---|---|
| Material | Enamelled (glass-fused-to-steel) plate |
| Type | Enamel steel water tank |
| Installation | Bolts connect |
| Wall thickness | 12 mm |
| Panel thickness | 2 – 4.5 mm by height |
| Panel sizes | 3 × 1 m 3 × 1 m 1.5 × 1 m 1 × 1 m 1 × 0.5 m 0.5 × 0.5 m |
| Storage water temperature | 4 – 100 °C |
| Applicable | Civil air defence engineering, fire protection |
| Transport package | Export standard |
| Certification | ISO 9001 |
| Origin | Dezhou City, Shandong Province, China |
Panels are 2 to 4.5 mm by height for an assembled wall of about 12 mm, with a service range of 4 to 100 °C covering mesophilic digestion.
| Tank height | Panel thickness | Typical use |
|---|---|---|
| Up to 1.5 m | 2 mm | Shallow or roof tank |
| 2.0 m | 3 mm | Standard sectional tank |
| 3.0 m | 4 mm | Deep tank, high static head |
| 4.0 m and above | 4.5 mm | Maximum height, braced |
Every enamel biogas tank is filled and held at full head before it leaves the factory, and no joint is allowed to weep. The plant is certified to ISO 9001 and the inspection certificate ships with the order; the full set is on our certifications page. The same specification is published on our Made-in-China storefront, where LVJIA is an audited supplier with a 5.0 store rating on Alibaba, 100% on-time dispatch and a response time under one hour.
Pricing for the enamel biogas tank starts at US$200 per m³, falling to US$180 from 10 and US$150 from 50, FOB Tianjin or Qingdao. The minimum order is one set and lead time is within 15 working days from Dezhou, Shandong. Roof type, gas holder connection, mixer mountings and heating coil positions are all fixed before the panels are fired.
Send the capacity you need and the space you have, and LVJIA returns an arrangement drawing with the panel schedule before you commit to anything. Our engineers answer specification questions directly through technical help, and the rest of the range sits on the Enameled water tank page.
If the material has to change, the GRP wastewater tank is the same tank in moulded GRP, for sites where no metal may touch the water, while the stainless steel industrial water tank builds it in stainless steel. Elsewhere in the enamelled range there is the enamel solar water tank for hot water storage and the enamel household water tank for household sizes.
At a glance
Panels are 2 to 4.5 mm by height for an assembled wall of about 12 mm, with a service range of 4 to 100 °C covering mesophilic digestion. Standard panel dimensions: 3 × 1 m; 2 × 1 m; 1.5 × 1 m; 1 × 1 m; 1 × 0.5 m; 0.5 × 0.5 m. Tank dimensions are configured from standard panels. Non-standard panel dimensions are not offered as standard options.
Panel thickness by tank height — Enamel Biogas Tank, Sludge Digester
| Tank height | Panel thickness | Typical use |
|---|---|---|
| Up to 1.5 m | 2 mm | Shallow or roof tank |
| 2.0 m | 3 mm | Standard sectional tank |
| 3.0 m | 4 mm | Deep tank, high static head |
| 4.0 m and above | 4.5 mm | Maximum height, braced |
LVJIA has pressed water-tank panels in Dezhou since the plant opened, and holds ISO 9001 with import and export rights of its own.
Request a quoteThe panel is pressed from 2 to 4.5 mm steel depending on where it sits in the wall, then enamelled on both faces. Assembled, the wall section measures 12 mm.
Product dimensions
Tolerance requirements
Every tank is filled and held at full head before dispatch and no joint is allowed to weep. The glaze is spark-tested for holidays before the panel leaves the line.
Typical performance — Enamel Biogas Tank, Sludge Digester
| Test | Method | Result |
|---|---|---|
| Hydrostatic | 48 h at full head | No weep at any joint |
| Glaze integrity | Spark test for holidays | Pass |
| Certification | ISO 9001 quality system | Held |
Send the capacity you need and the space you have, and LVJIA returns an arrangement drawing with the panel schedule before you order.
