A modular GRP water tank built to the space you have — 1 m and half-metre panels step the capacity to fit the room.
Indicative — the quotation confirms the final figure US$380 Lead time within 15 working days · ex Dezhou, Shandong
SKU LVJ-GRP-MOD
What buyers said once the tank was on site — every review left on our Alibaba store, in their own words.
The modular GRP water tank from LVJIA is built on the GRP/FRP/SMC panel system at our own plant in Dezhou, Shandong. It is the answer when the plant room is an awkward shape and a fixed-size tank simply will not go in.
A modular GRP water tank is a bolted sectional tank built from hot-press moulded SMC panels. Sheet moulding compound is a glass-reinforced polyester pressed at heat and pressure into a single stiff panel, so the finished wall is inert, light and dimensionally exact. Panels come in 3 × 1 m; 2 × 1 m; 1.5 × 1 m; 1 × 1 m; 1 × 0.5 m; 0.5 × 0.5 m, which is how the tank is fitted to an awkward plant room rather than the plant room to the tank. LVJIA builds it from 1 to 5000 m³.
Because the panel comes as 1 × 1 m, 1.5 × 1 m, 2 × 1 m, 1 × 0.5 m and 0.5 × 0.5 m, the tank can be stepped in half-metre increments in any direction. An L-shaped basement, a low ceiling, a doorway that will not take anything bigger than a panel — all of it is handled by changing the module mix rather than by machining a special. Send the room dimensions and the volume you need, and LVJIA works out the arrangement that gets the most water into the space available.
The wall is a moulded SMC panel — 8 mm on a shallow tank, thickening to 16 mm at full height, with no metal in contact with the water at all, so there is nothing to corrode, nothing to coat and nothing to earth. Panels are drawn together on an external flange with stainless bolts and a food-grade gasket, and internal tie rods brace the larger shells. Because a single panel weighs what one person can carry, the whole tank goes up a stairwell and through a standard doorway, which is why so many of these are retrofits into buildings that were never designed to hold a tank.
| Model number | Customized size |
|---|---|
| Material | FRP / SMC moulded composite panel |
| Type | SMC sectional water tank |
| Installation | Bolt connection |
| Panel sizes | 3 × 1 m 3 × 1 m 1.5 × 1 m 1 × 1 m 1 × 0.5 m 0.5 × 0.5 m |
| Wall thickness | 8 mm |
| Colour | White, blue or black |
| Capacity range | 1 – 5000 m³ |
| Transport package | Wooden crate |
| HS code | 7310100090 |
| Certification | ISO 9001 |
| Origin | Dezhou City, Shandong Province, China |
Capacity runs from 1 to 5000 m³. Height is built in whole or half metres up to about 4 m with internal tie rods, and the plan can be any rectangle the module grid allows.
| Tank height | Panel thickness | Typical use |
|---|---|---|
| Up to 1.0 m | 8 mm | Shallow or roof-mounted tank |
| 1.5 – 2.0 m | 8 – 10 mm | Standard sectional tank |
| 2.5 – 3.0 m | 10 – 13 mm | Deep tank, internal tie rods |
| 3.5 – 4.0 m | 13 – 16 mm | Maximum height, reinforced base |
Every modular GRP water tank is filled and held at full head before it leaves the factory, and no joint is allowed to weep. The plant is certified to ISO 9001 and the inspection certificate ships with the order; the full set is on our certifications page. The same specification is published on our Made-in-China storefront, where LVJIA is an audited supplier with a 5.0 store rating on Alibaba, 100% on-time dispatch and a response time under one hour.
Pricing for the modular GRP water tank starts at US$20 per panel, falling to US$19 from 10 and US$18 from 50, FOB Tianjin or Qingdao. The minimum order is one set and lead time is within 15 working days from Dezhou, Shandong. Send a dimensioned sketch of the space and the capacity required; the arrangement drawing comes back with the panel schedule.
Send the capacity you need and the space you have, and LVJIA returns an arrangement drawing with the panel schedule before you commit to anything. Our engineers answer specification questions directly through technical help, and the rest of the range sits on the GRP/FRP/SMC water tank page.
Where another material suits the site better, the modular galvanized water tank is the same tank in hot-dip galvanized steel, for sites where a heavier steel wall suits the head, while the enamel modular water tank builds it in glass-fused-to-steel. Elsewhere in the GRP/FRP/SMC range there is the household GRP water tank for household sizes and the GRP cooling water tank for cooling circuits.
At a glance
Capacity runs from 1 to 5000 m³. Height is built in whole or half metres up to about 4 m with internal tie rods, and the plan can be any rectangle the module grid allows. Standard panel dimensions: 3 × 1 m; 2 × 1 m; 1.5 × 1 m; 1 × 1 m; 1 × 0.5 m; 0.5 × 0.5 m. Tank dimensions are configured from standard panels. Non-standard panel dimensions are not offered as standard options.
Panel thickness by tank height — Modular GRP Water Tank, Built to Size
| Tank height | Panel thickness | Typical use |
|---|---|---|
| Up to 1.0 m | 8 mm | Shallow or roof-mounted tank |
| 1.5 – 2.0 m | 8 – 10 mm | Standard sectional tank |
| 2.5 – 3.0 m | 10 – 13 mm | Deep tank, internal tie rods |
| 3.5 – 4.0 m | 13 – 16 mm | Maximum height, reinforced base |
LVJIA has pressed water-tank panels in Dezhou since the plant opened, and holds ISO 9001 with import and export rights of its own.
Request a quoteThe panel is sheet moulding compound — glass fibre in a polyester matrix, pressed under heat into a single stiff piece. It is inert, it does not conduct, and it weighs a fraction of the equivalent steel panel.
Product dimensions
Tolerance requirements
Every tank is filled and held at full head before dispatch and no joint is allowed to weep. Panels are checked for flatness and bolt-hole pitch as they come off the press.
Typical performance — Modular GRP Water Tank, Built to Size
| Test | Method | Result |
|---|---|---|
| Hydrostatic | 48 h at full head | No weep at any joint |
| Panel flatness | Gauge check off the press | ± 1.0 mm |
| Potable contact | Food-grade resin and gasket | Pass |
Send the capacity you need and the space you have, and LVJIA returns an arrangement drawing with the panel schedule before you order.
